ViaTag™ Haloalkane Ligands

Bright fluorescent ligands for the HaloTag® self-labeling protein tag.

Rapid & Covalent

Rapid labeling of HaloTag® with minimal wash steps required

Versatile Labeling

Flexible options for intracellular or cell surface targets, label live or fixed cells

Widest Selection of Colors

Choose from 11 bright colors from UV to near-IR

What Are HaloTag® Fusion Proteins?

HaloTag® fusion proteins are a powerful tool for labeling proteins in cells with high specificity and resolution. The HaloTag® system uses a genetically engineered protein tag that forms a rapid, covalent, and irreversible bond with synthetic fluorescent haloalkane ligands. Because the bond is covalent and stable, labeled fusion proteins can be imaged under demanding conditions with minimal background, making HaloTag® an ideal choice for live cell fluorescence microscopy, flow cytometry, or other fluorescence-based methods.

Principle of labeling HaloTag® protein tags with ViaTag™ Haloalkane Ligands. A protein of interest (purple) fused to the HaloTag® fusion protein (black) is spec... See More

Discover Flexible & Cost-Effective Labeling with ViaTag™

ViaTag™ Ligands

ViaTag™ Haloalkane Ligands deliver bright, durable labeling of HaloTag® fusion proteins with minimal background, no extensive wash steps, and lower overall cost compared to other HaloTag® ligands. Available in both cell membrane-permeant and impermeant formats, they enable direct labeling of intracellular or cell-surface proteins across 11 fluorescent colors from UV to near-IR. ViaTag™ Ligands are supplied as stable, ready-to-use DMSO stock solutions for streamlined labeling protocols.

Key Features

  • Rapid labeling of HaloTag® self-labeling tags
  • Stable and ready-to-use DMSO stock solutions
  • No need for extensive wash steps
  • Label intracellular or cell-surface targets
  • Widest selection of colors from UV to near-IR
  • Cost-effective alternative to other haloalkane ligands

Choose from 11 bright colors, with flexible options for intracellular or cell surface targets

ViaTag™ Haloalkane Ligand staining. Top row: HeLa cells were transiently transfected with NLS3-HaloTag® expression vector targeting HaloTag® to the cell nucleus... See More
HeLa cells transiently transfected with NLS3-HaloTag® expression vector were fixed with PFA, then stained with the indicated ViaTag™ ligand in PBS for 30 minute... See More

ViaTag™ Haloalkane Ligands

DyeCatalog No.Ex/Em (nm)SizeCell membrane permeabilityLaser lineChannel for detection
ViaTag™ 355/450 Haloalkane Ligand, 1000X in DMSO10301349/44030 uLPermeant355 nm (UV)DAPI
ViaTag™ 400/460 Haloalkane Ligand, 1000X in DMSO10302391/45230 uLPermeant405 nmDAPI, Alexa Fluor® 405, Pacific Blue®
ViaTag™ 500/525 Haloalkane Ligand, 1000X in DMSO10303504/52730 uLPermeant488 nmFITC
ViaTag™ 540/565 Haloalkane Ligand, 1000X in DMSO10304543/57230 uLPermeant555 nm, 561 nmRhodamine, dsRed, PE
ViaTag™ 650/680 Haloalkane Ligand, 1000X in DMSO10305653/67430 uLPermeant640 nmAlexa Fluor® 647, APC
ViaTag™ 490/525 Haloalkane Ligand, 1000X in DMSO10306493/51730 uLImpermeant488 nmFITC
ViaTag™ 550/575 Haloalkane Ligand, 1000X in DMSO10307551/57730 uLImpermeant555 nm, 561 nmRhodamine, dsRed, PE
ViaTag™ 595/615 Haloalkane Ligand, 1000X in DMSO10308593/61530 uLImpermeant561 nm, 594 nmTexas Red®
ViaTag™ 640/660 Haloalkane Ligand, 1000X in DMSO10309642/66330 uLImpermeant640 nmAlexa Fluor® 647, APC
ViaTag™ 660/680 Haloalkane Ligand, 1000X in DMSO10310662/68230 uLImpermeant640 nmAlexa Fluor® 660
ViaTag™ 740/765 Haloalkane Ligand, 1000X in DMSO10311742/76730 uLImpermeant730 nmAlexa Fluor® 750

ViaTag is a trademark of Biotium, Inc.; HaloTag is a registered trademark of Promega Inc.; Alexa Fluor, Pacific Blue, and Texas Red are registered trademarks of Thermo Fisher Scientific.

FAQs

Bioscience kits
The guaranteed shelf life from date of receipt for bioscience kits is listed on the product information sheet. Some kits have an expiration date printed on the kit box label, this is the guaranteed shelf life date calculated from the day that the product shipped from our facility. Kits often are functional for significantly longer than the guaranteed shelf life. If you have an older kit in storage that you wish to use, we recommend performing a small scale positive control experiment to confirm that the kit still works for your application before processing a large number of samples or precious samples.

Antibodies and other conjugates
The guaranteed shelf life from date of receipt for antibodies and conjugates is listed on the datasheet sheet which can be downloaded on the product page. Antibodies and other conjugates often are functional for significantly longer than the guaranteed shelf life. If you have an older conjugate in storage that you wish to use, we recommend performing a small scale positive control experiment to confirm that the product still works for your application before processing a large number of samples or precious samples.

For lyophilized antibodies, we recommend reconstituting the antibody with glycerol and antimicrobial preservative like sodium azide for the longest shelf life (note that sodium azide is not compatible with HRP-conjugates).

Chemicals, dyes, and gel stains
Biotium guarantees the stability of chemicals, dyes, and gel stains for at least a year from the date you receive the product. However, the majority of these products are highly stable for many years, as long as they are stored as recommended. Storage conditions can be found on the product information sheet or product safety and data sheet, material safety data sheet, and on the product label. Fluorescent compounds should be protected from light for long term storage.

If you have a Biotium compound that has been in storage for longer than one year that you wish to use, we recommend performing a small scale positive control experiment to confirm that the compound still works for your application before processing a large number of samples or precious samples.

Expiration date based on date of manufacture (DOM)
If your institution requires you to document expiration date based on date of manufacture for reagents, please contact [email protected] for assistance.

Chemical products with special stability considerations:

Esters

Ester compounds include the following:

  • Succinimidyl esters (SE, also known as NHS esters), such as our amine-reactive dyes
  • Acetoxymethyl esters (AM esters), such as our membrane-permeable ion indicator dyes
  • Diacetate-modified dyes, like ViaFluor™ 405, CFDA, and CFDA-SE cell viability/cell proliferation dyes

Ester dyes are stable in solid form as long as they are protected from light and moisture. Esters are not stable in aqueous solution. Concentrated stock solutions should be prepared in anhydrous DMSO (see Biotium catalog no. 90082). Stock solutions in anhydrous DMSO can be stored desiccated at -20°C for one month or longer. Esters should be diluted in aqueous solution immediately before use. Succinimidyl esters (SE) should be dissolved in a solution that is free of amine-containing compounds like Tris, glycine, or protein, which will react with the SE functional group. AM esters and diacetate compounds should be dissolved in a solution that is free of serum, because serum could contain esterases that would hydrolyze the compound.

A note on CF® Dye succinimidyl ester stability

Succinimidyl esters (SE) are generally susceptible to hydrolysis, which can result in lower labeling efficiency. Many commercially available fluorescent dyes used for life science research are heavily sulfonated dyes which makes them particularly hygroscopic, worsening the hydrolysis problem. In addition, for several commercially available SE reactive dyes, the SE group is derived from an aromatic carboxylic acid, while the SE group in all of Biotium’s CF® Dyes is prepared from an aliphatic carboxylic acid. This structural difference reduces the susceptibility of CF® Dye SE reactive groups to hydrolysis, resulting in relatively stable reactive dyes with consistently higher labeling efficiency compared to other SE derivatives of other fluorescent dyes.

Maleimides, MTS and thiosulfate dyes
Like the succinimidyl ester dyes, these dyes are also susceptible to hydrolysis, although generally to a much lower degree. Thus, for long term storage, anhydrous DMSO is recommended for making stock solutions.

Other reactive dyes
Amines, aminooxy (also known as oxylamine), hydrazide, azide, alkyne, BCN, and tyramide reactive dyes, as well as dye free acids, are generally stable in aqueous solution when stored at -20°C for 6-12 months or longer, as long as no compounds are present that may react with the dye’s functional group. See the product information sheets for specific reactive dyes more information.

Coelenterazines and D-luciferin

Coelenterazines are stable in solid form when stored as recommended; they are not stable in aqueous solution. Concentrated coelenterazine stock solutions (typically 1-100 mg/mL) should be prepared in ethanol or methanol; do not use DMSO or DMF to dissolve coelenterazines, because these solvents will oxidize the compounds. Ethanol or methanol stocks of coelenterazine can be stored at -20°C or below for six months or longer; alcohol stocks may evaporate during storage, so use tightly sealing screw cap vials and wrap the vials with Parafilm for long term storage. Propylene glycol also can be used as a solvent to minimize evaporation. If the solvent evaporates, the coelenterazine will still be present in the vial, so note the volume in the vial prior to storage so that you can adjust the solvent volume to correct for evaporation if needed. Prepare working solutions in aqueous buffers immediately before use. Coelenterazines are stable for up to five hours in aqueous solution.

Aquaphile™ coelenterazines are water soluble formulations of coelenterazines. They are stable in solid form when stored as recommended. Aquaphile™ coelenterazines should be dissolved in aqueous solution immediately before use. They are stable for up to five hours in aqueous solution.

Note that coelenterazines are predominantly yellow solids, but may contain dark red or brown flecks. This does not affect product stability or performance. If your coelenterazine is uniformly brown, then it is oxidized and needs to be replaced.

D-luciferin is stable in solid form and as a concentrated stock solution when stored as recommended; it is not stable at dilute working concentrations in aqueous solution. Prepare concentrated D-luciferin stock solutions (typically 1-100 mg/mL) in water, and store in aliquots at -20°C or below for six months or longer. Prepare working solutions immediately before use.

Some of our large volume light-sensitive products are packaged in amber bottles or amber glass vials, which are easy to handle and protect the products from light. However, amber micro packaging vials (0.5 mL or 2 mL) make it very difficult to see small quantities of dye when preparing solutions or pipetting. Therefore, we only package photoreactive dyes like PMA or PMAxx™ in amber micro packaging vials. Some of our reactive dyes are packaged in transparent vials, then sealed inside a moisture-resistant foil bag, which also will protect them from light.

Other fluorescent dyes in transparent vials should stored in the dark for long term storage. It's fine to store dye vials uncovered in a windowless refrigerator or freezer with an automatic light shut-off. If dyes will be stored in a glass-front (deli-style) refrigerator, walk-in refrigerator/freezer, or at room temperature with constant light exposure, they should stored in a non-transparent box (like a white cardboard freezer box), in a closed drawer, in a black plastic bag, or covered with aluminum foil.

Fluorescent dyes generally are not sensitive to brief light exposure while they are being handled on the bench during an experiment. To be on the safe side, we usually loosely cover tube racks with a piece of foil if the dye vials are going to be out on the bench for more than 30 minutes or so. But most dyes are stable enough that even accidentally leaving them on the bench for a day will not affect performance. When handling photoreactive dyes like EMA, PMA, or PMAxx, we take the extra precaution of dimming the lights.
